Go Kart Clutch 3/4 Bore 12T Tooth with 35 Chain Centrifugal Minibike Engines

Description

Specifications:
Shaft size: 3/4″ Bore
Chain Size: #35 Chain ( 4 Feet )
Tooth Count: 12 Tooth
Clutch Diameter: 107 mm
Clutch Height: 55 mm
Engagement Speed: 2300±300 RPM
Recommended Engine: 2HP – 6.5HP, 3/4″ shaft with flat key
Fitment:
2-6.5hp Honda & Honda cloned engines GC160, GC190, GX120, GX140, GX160, GX200
Perfect for Go Kart, Mini bike, Fun Kart
Common clutch for 3.5-7hp engines using #35 Chain
Briggs & Stratton and 2 – 6.5 HP with 3/4″ Shaft
Tecumseh Engines 2 – 7 HP with 3/4″ Shaft
Other engines with 3/4 crank shaft and 3/16″ key way
Most 5.5 HP clones, 6.5 HP clones and 4-7HP motors in all brands
This Kit Includes:
1 x 12 Teeth Centrifugal Clutch
1 x #35 Chain
2 x Set Screws
1 x Connecting Link

Oiling the clutch is extremely important
If heat damage occurs, the clutch will never disengage and the machine will start taking off by itself as soon as you start the engine. This is very dangerous! You can see heat damage inside the clutch drum, the metal turns from black to a blue color.
Behind the snap ring, next to the sprocket teeth at the end of the clutch. There’s an internal bronze bushing behind the snap ring that requires lubrication and it’s up to you to put it there each time.
It’s a good idea to oil the chain at the same time. If the chain gets kinky from lack of oil it should be replaced before it damages the clutch sprocket. A new chain is cheaper than a new clutch.
